CMS WP-3B Series Microscopes

SKU
wp-3
$390.00

This zoom stereo microscope is ideal for laboratory and industrial applications. Using its high resolution, great depth, and a large field of view, it is the perfect instrument for viewing any three-dimensional specimen or large objects. The solid cross block and brass inserts improve movement, while the friction collar secures the peg and allows the microscope to rotate around a vertical axis. Its rotating, swiveling, and tilting functionalities allow for it to cover wide, horizontal and vertical viewing areas; making it sure to meet your flexibility requirements. Packed in a fitted Styrofoam box, and includes a dust cover and an instruction manual

  • Head: Binocular, 45° inclined, rotates 360°
  • Interpupillary Adjustment: 54 to 76mm
  • Diopter Adjustment: ±6 on both ocular tubes
  • Eyepiece: 10x WF / 20mm high eye point
  • Zoom Range: 0.7x - 4.5x, 1:6.4 zoom ratio
  • Magnification Range: 7x - 45x
  • Working Distance: 100mm standard
  • Focusing: Heavy duty rack and pinion focusing arm with tension adjustment
  • Stand: Single arm boom stand
  • Light Source: Optional
  • Dimensions: 22” x 18” x 12”-38lbs
  • Warranty: 5 year limited warranty (excluding bulbs)
More Information
MSRP 525.00
STEM Approved No
Power None
