MOTICAM PROS5 LITE
SKU
Add to Compare
1100600101101
$1,199.00
Moticam Pro S5 Lite with 5MP resolution delivers best conditions to document large samples from all biological/medical fields, at the same time showing high low-light sensitivity. The global shutter readout helps to accelerate data transfer moving/fast phenomena from biology and industrial production.
| Model | Moticam Pro S5 Lite |
| Sensor Type | sCMOS |
| Sensor Size | 2/3" |
| Imaging Area | 11.1mm (Diagonal) |
| Capture Resolution Info | 5MP |
| Live display mode through USB | 2448x2048, 1224x1024 pixels |
| Pixel size | 3.45x3.45μm |
| Scan mode | Progressive |
| Shutter mode | Global shutter |
| Data transfer | USB 3.1 |
| Max. frames per second (fps) | 2448x2048 @ 37.5fps 1224x1024 @ 88.4fps (*) |
| Exposure time | 14 μsec to 2 sec |
| Operating temperature | From -10 to +60 Degrees Celsius non condensing |
| Max. signal to noise ratio | 0.1mV @1/30 sec |
| Sensitivity | 1146mV(G) @ 1/30 sec |
| Support device | TWAIN, SDK and DirectShow Driver |
| Supported OS | Windows 7/8/10, MAC OSX, Linux or higher |
| Minimum computer requirements | 2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB |
| Lens mount | C-Mount |
| Software | Motic Images Plus 3.0 for Windows, OSX and Linux |
| Functions | Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system. |
| Power supply | 5V (From USB Port) |
| Package includes | CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for Windows/OSX/Linux |
| Other features | (*) Frames per second under optimal lighting conditions and in compliance with computer technical requirements. |
| MSRP | 1,143.00 |
|---|---|
| STEM Approved | No |
| Connection Type | USB |
| Power | None |
